Dayton Audio CFC150-4 5-1/4″ Carbon Fiber Woofer 4 Ohm

The Dayton Audio CFC150-4 is a compact 5.25″ carbon fiber woofer with 4 ohms impedance, 89 dB sensitivity and a 50 to 7,000 Hz usable frequency range for clean, detailed performance in compact speaker designs.

Highlights of the Dayton Audio CFC150-4

• Woven carbon fiber cone combines low mass with excellent rigidity
• 3.5 mm Xmax delivers strong low-frequency capability from a compact woofer
• Raised pole piece supports a more symmetrical magnetic field for controlled displacement
• Vented pole piece improves voice coil cooling and helps reduce power compression
• 89 dB sensitivity and 50 to 7,000 Hz response suit compact 2-way designs

Product details Dayton Audio CFC150-4

Dayton Audio CFC150-4 5.25″ Carbon Fiber Woofer 4 Ohm

The Dayton Audio CFC150-4 is a compact woofer built around a woven carbon fiber cone. This cone material combines low moving mass with high rigidity, helping the driver reproduce clean and detailed sound across its usable 50 to 7,000 Hz frequency range.

With a 4 ohms nominal impedance, 3.6 ohms Re and 89 dB sensitivity at 2.83V/1m, the CFC150-4 is well suited for efficient compact speaker designs. Its 40 watts RMS power handling gives it practical output capability for small-format systems.

The motor structure uses a raised pole piece to create a more symmetrical magnetic field, supporting controlled displacement. A vented pole piece improves voice coil cooling, helping to reduce power compression during higher-output playback.

Thanks to its 3.5 mm Xmax, 77 Hz Fs and response extending up to 7,000 Hz, the CFC150-4 is a strong choice for compact 2-way projects and bass-mid woofer applications where detailed midrange and useful low-frequency capability are needed from a small driver.
