Dayton Audio DTA-PRO mini stereo amplifier
€229.95
The Dayton Audio DTA Pro provides a rich feature set including Bluetooth, USB DAC, and even a wireless remote control. With 50 watts per channel at 4 ohms, the DTA-Pro provides enough power to run even the most demanding speakers. High efficiency paired with low THD offers up an impeccably clean, uncolored audio experience.
Available on backorder
Highlights
- Powerful remote controlled amplifier and DAC all in a small package
- Several input options: Bluetooth, 3.5 mm, coaxial, optical, and USB
- Wireless remote controls source input, EQ, and volume
- High speed 192 kHz/24-bit DAC sampling rate
Product details
Dayton Audio DTA-PRO 100W Class D Bluetooth Amplifier with USB DAC IR Remote and Sub Output
Rediscover your favorite music with the DTA-PRO. This all-in-one amplifier starts with a refined, brushed aluminum case and fills it chock full of features. This powerful 50 watt per channel amplifier offers clean and precise sound with a number of convenient input options. For convenience and usability the DTA-PRO comes equipped with Bluetooth 4.2 with aptX. For the very best in audio quality the DTA-PRO offers an optical / coaxial input capable of 192 kHz/24-bit sampling rate. Other input methods also include USB and a 3.5mm stereo jack.
Included with the DTA-PRO is a full function wireless remote which allows for total control over the amplifiers number of presets and features including EQ presets, bass / treble adjustment, and even track control when utilizing the Bluetooth or DAC input.
The DTA-PRO also offers a powerful line level output for connecting a powered subwoofer. At nearly 3 VRMS the subwoofer output provides a powerful signal to give your powered subwoofer the signal it needs to really pound.
Specifications: Power output: 2 x 50 watts @ 4 ohms • Frequency response: -1.5 dB (20 Hz-20 kHz) • THD+N: 0.09% at 100mV input • Dynamic range: 129 dB at 1 kHz • SNR: -107 dB at 1 kHz • Inputs: USB, digital optical, digital coaxial, stereo 3.5 mm, Bluetooth • Sub level: 2.7VRMS maximum • Sampling bit rate: 192 kHz/24-bit (coaxial and optical), 96 kHz/24-bit (USB) • Electrical requirement: 24V-32V • Minimum input sensitivity: 1.1V • Maximum input sensitivity: 2.5V • Channel separation: -60 dB • Efficiency: 88% • Chipset: SA9023+CS8416+TAS5342A+TAS5508C+DAC PCM1808+NE5532 • Dimensions: 1.2″ H x 5.2″ W x 5″ D.
Specifications
| Article number | DTA-PRO |
| EAN | 0848791005312 |
| Rated power output (RMS) | 2 x 50 Watts at 4 ohms |
| Bridged power output (RMS) | – |
| Minimum load | 4 ohms |
| Signal-to-noise ratio (SNR) | -107dB (at 1KHz) |
| Distortion | 0.09% at 100 mV input THD+N |
| Distortion bridged | – |
| Efficiency | 88% |
| Frequency response | 20 – 20,000 kHz (-1.5 dB) |
| Input impedance | 20 Kohms (AUX) |
| Input sensitivity | 1.1 – 2.5 V |
| Auto turn-on sensitivity | – |
| DSP | – |
| DAC | check |
| Maximum sampling rate | <p>Coaxial/optical: 192 kHz / 24 bit<br />USB: 96 kHz / 24 bit</p> |
| Circuit Topology | <p>SA9023, CS8416, TAS5342A, TAS5508C<br />DAC PCM1808, NE5532 </p> |
| Amplifier classification | D |
| Speaker output channels | 2 |
| Subwoofer output channel | – |
| Analog in/out | -/- |
| Optical S/PDIF in/out | 1/- |
| Coaxial in/out | 1/- |
| RCA in/out | -/- |
| AUX in/out | 1/- |
| Bus in/out | -/- |
| XLR in/out | -/- |
| USB | check |
| Memory card slot | – |
| Network connection | – |
| Headphone jack | – |
| Subwoofer pre-out | check |
| Bluetooth | 4.2 |
| NFC | – |
| Wi-Fi | – |
| Banana plug compatible | check |
| Remote control | check |
| App control | – |
| Auto turn-on | – |
| Accepted file formats | – |
| Equalizer (EQ) adjustment | check |
| Equalizer (EQ) profiles | check |
| Multi zone/room | – |
| Crossover frequency adjustment | 150 Hz fixed low pass |
| Bridge mode | – |
| Power requirements | 24V – 32 VDC |
| Power inlet connector | DC jack |
| Power consumption | – |
| Stand-by power consumption | – |
| Dimensions (D x W x H) | 127 x 132 x 30.5 mm |
| Case material | Brushed aluminum |
| Power output | 2 x 50 watts @ 4 ohms |
| THD+N | 0.09% at 100mV input |
| Dynamic range | 129 dB at 1 kHz |
| SNR | -107 dB at 1 kHz |
| Inputs | USB, digital optical, digital coaxial, stereo 3.5 mm, Bluetooth |
| Sub level | 2.7VRMS maximum |
| Sampling bit rate | 192 kHz/24-bit (coaxial and optical), 96 kHz/24-bit (USB) |
| Electrical requirement | 24V-32V |
| Minimum input sensitivity | 1.1V |
| Maximum input sensitivity | 2.5V |
| Channel separation | -60 dB |
| Chipset | SA9023+CS8416+TAS5342A+TAS5508C+DAC PCM1808+NE5532 |
| Dimensions | 1.2" H x 5.2" W x 5" D. |
| Article number | DTA-PRO |
| EAN | 0848791005312 |
| Rated power output (RMS) | 2 x 50 Watts at 4 ohms |
|---|---|
| Minimum load | 4 Ohms |
| Signal-to-noise ratio (SNR) | -107dB (at 1KHz) |
| Distortion | 0.09% at 100 mV input THD+N |
| Efficiency | 88% |
| Frequency response | 20 – 20,000 kHz (-1.5 dB) |
| Input impedance | 20 Kohms (AUX) |
| Input sensitivity | 1.1 – 2.5 V |
| DAC | check |
| Maximum sampling rate | Coaxial/optical: 192 kHz / 24 bitUSB: 96 kHz / 24 bit |
| Circuit Topology | SA9023, CS8416, TAS5342A, TAS5508CDAC PCM1808, NE5532 |
| Amplifier classification | Class-D |
| Speaker output channels | 2 |
| Analog in/out | -/- |
| Optical S/PDIF in/out | 1/- |
| Coaxial in/out | 1/- |
| RCA in/out | -/- |
| AUX in/out | 1/- |
| Bus in/out | -/- |
| XLR in/out | -/- |
| USB | check |
| Subwoofer pre-out | check |
| Bluetooth | 4.2 |
| Banana plug compatible | check |
| Remote control | check |
| Equalizer (EQ) adjustment | check |
| Equalizer (EQ) profiles | check |
| Crossover frequency adjustment | 150 Hz fixed low pass |
| Power Requirements | 24V – 32 VDC |
| Power inlet connector | DC Jack |
| Dimensions (D x W x H) | 127 x 132 x 30.5 mm |
| Case material | Brushed aluminum |
| Power output | 2 x 50 watts @ 4 ohms |
| THD+N | 0.09% at 100mV input |
| Dynamic Range | 129 dB at 1 kHz |
| SNR | -107 dB at 1 kHz |
| Inputs | USB, digital optical, digital coaxial, stereo 3.5 mm, Bluetooth |
| Sub level | 2.7VRMS maximum |
| Sampling bit rate | 192 kHz/24-bit (coaxial and optical), 96 kHz/24-bit (USB) |
| Electrical requirement | 24V-32V |
| Minimum input sensitivity | 1.1V |
| Maximum input sensitivity | 2.5V |
| Channel separation | -60 dB |
| Chipset | SA9023+CS8416+TAS5342A+TAS5508C+DAC PCM1808+NE5532 |
| Dimensions | 1.2″ H x 5.2″ W x 5″ D. |
| Specification | Bluetooth, Subwoofer pre-out |
