Ground Zero Reference 2PURE

<p>The Reference Line stands for selected high-end products with outstanding sound-quality.<br>The GZPA Reference 2 PURE is a high-end 2-Channel amplifier with a dual-mono direct-signal layout.<br>Because of the separated channels and direct signal paths, it allows an excellent sound quality performance.<br>The direct signal paths could be realized by leaving out all sound affecting parts, potentiometers and switches.</p>Technical Data: – High-End pure sound quality amplifier – 1 Ohm stabile stereo / 2 Ohm bridged – Symmetrical dual-mono direct-signal layout – Shielded and separated dual power supply – Continuously variable Bias Setting Class AB – nearly Class A – Adjustable input sensitivity – Soft delayed remote turn-on – Power & Protection indicator – Thermal, over current, speaker short, Speaker DC protection – Temperature-sensitive controlled fan – Plexiglas bottom plate – White LED illumination inside – High quality Rhodium RCA plugs – Selected high-end SANKEN® transistors – Low distortion LM4562 OP with 0.00003% THD+N – Ground Zero exclusive Mundorf Mcap® capacitors – Special made audio-optimized Mundorf secondary capacitors for maximum buffering – Capsuled ALPS potentiometers with channel separated level adjustment and summarize-function – Low-tolerance Vishay Dale emitter-resistors for accurate bias point stabilization – Copper anodized aluminum strand cast heatsinkOutput Power @ 4 Ohm (CEA*)2 x 420 WOutput Power @ 2 Ohm (CEA*)2 x 750 WOutput Power @ 1 Ohm (CEA*)2 x 1150 WBridge mode @ 4 Ohm (CEA* / 10% THD)1 x 1800 WBridge mode @ 2 Ohm (CEA* / 10% THD)1 x 2700 WDimensions 59 x 6,75 x 23,6 cm.Model specification: PLUTONIUM
