Helix HEC HD-Audio USB – DSP PRO MK3

<p>With this unit, you can add a HD USB input to your DSP PRO MK3 amplifier.</p>Technical Data: Note: The HD-AUDIO USB-INTERFACE has two operating modes.Full Speed Mode (default): Highest compatibility with all Android, iOS, macOS and Windows devices. Supports sample rates up to 96 kHz / 32 Bit. No driver installation necessary.High Speed Mode: Compatible with most of all Android ( Version 6), iOS, macOS and Windows devices. Supports sample rates up to 192 kHz / 32 Bit. An additional driver installation for Windows devices is necessary to use sampling rates higher than 96 kHz / 32 Bit.Note: No connection wires included. A MiniUSB wire is needed for most configurations. If your device does not have the latest software version, you will also need a MicroUSB OTG cable for Android devices and a Camera Connection Kit or Lightning to USB cable for Apple devices.Attention: The HD-AUDIO USB-INTERFACE does not support charging.Technical dataInput sampling rate 32 kHz to 192 kHz / 16 Bit, 24 Bit or 32 BitInput format PCMSupported device operating systems Windows, macOS, iOS, AndroidAdditional features Asynchronous USB connectionwith own clock generators forhighest jitter immunityCompatibilityHELIX DSP ULTRAScope of delivery1 x HEC HD-AUDIO USB-INTERFACE module1 x Device-specific side panel1 x Allen screw1 x Allen key1 x Instruction manual
