miniDSP C-DSP 8×12 V2.0 Boxed Digital Audio Processor for Mobile/Car audio

Highlights

• 400MHz 32bit Sharc Floating point processor, Up to 192kHz processing
• Digital and analog inputs (Low/High levels), 12 analog outputs
• Flexible DSP processing blocks, Rear Fill processing (L-R, L+R..) thanks to internal matrix
• Windows/Mac compatible GUI
• Remote control or preset/master & sub volume control
• V2.0

Product details

miniDSP C-DSP 8×12 V2.0 Digital Signal Processor for Mobile/Car audio

Note: This product comes with a coupon (€9,50) for one free miniDSP plugin download.

The C-DSP 8×12 is miniDSP’s next-generation processor for high-end mobile/car audio. The powerful 400 MHz SHARC floating-point processor provides pristine high-resolution audio at internal sample rates up to 192 kHz. With a wealth of inputs and outputs in a compact, rugged enclosure, the C-DSP 8×12 is suitable for installations from simple stereo, through surround systems with subwoofer integration, up to advanced multichannel active systems.

The driverless USB interface is used to configure miniDSP’s powerful but easy-to-use audio processing: parametric EQ on all inputs and outputs, compressors and adjustable time delay on all outputs, crossovers up to 48 dB/octave, and an advanced matrix mixer. Four complete processing configurations are stored in flash memory for instant recall with a wired or infrared remote.

Hardware features dedicated to the vehicle environment include an on-board isolated power supply, remote trigger input/output, a wired remote for dash or console mounting, and a microSD card slot for offline configuration and firmware updates.

Documents

• C-DSP 8×12 – Datasheet
• C-DSP 8×12 – User Manual

What’s in the box?

• 1 x C-DSP 8×12 V2.0 DSP processor
• 1 x USB cable
• 1 x remote unit
• 1 x 5m long remote cable
• 1 x Coupon code for miniDSP plugin download.

Typical Application

Mechanical Specifications
