Mundorf MLGO+550-470 | 470 µF| 20% | 550 V Mlytic AG+ Power Capacitor

Highlights of the Mundorf MLGO+550-470

• 470 µF capacitance with ±20 % tolerance for reliable energy storage
• High dielectric strength rated to 550 V DC
• Non-magnetic aluminium foil with MLytic winding technology
• Self-adhesive MSPA mounting pad with 1.2 mm tinned copper wire leads

Product details Mundorf MLGO+550-470

Mundorf MLGO+550-470 MLytic AG+ Power Capacitor

The Mundorf MLGO+550-470 MLytic AG+ is a high-performance power capacitor designed for audio-grade and high voltage power supply applications. With a capacitance of 470 µF and a tolerance of ±20 %, it ensures stable filtering and energy storage in demanding circuits. Its dielectric strength of 550 V DC provides ample headroom for tube amplifiers and other high voltage designs.

Constructed with aluminium foil as conductor material and utilizing Mundorf’s MLytic winding technology, this capacitor delivers low loss characteristics and dependable long-term performance. The non-magnetic design supports clean operation in sensitive audio environments where minimal interference is essential.

The compact cylindrical housing measures Ø35 mm with a height of 70 mm, making integration straightforward in a wide range of chassis layouts. Straight, tinned copper wire leads with a diameter of 1.20 mm and 8 mm length ensure secure electrical connection and easy installation.

For enhanced mechanical stability, the integrated self-adhesive MSPA mounting pad reduces vibration and relieves traction on the leads. With an operating temperature range from -40 °C to +85 °C, the MLGO+550-470 is built to perform reliably across diverse environmental conditions.
