PAW 30 ND – 8 Bass-midwoofer

329.95

  • Octagonal die cast basket
  • Paper membrane
  • 75 mm voice coil for high power handling
  • Til voice coil former
  • Vented spider
  • Additional vented air gap (8 holes)
  • 10 mm t-yoke venting
  • M shape surround for high excursion
  • Connex spider
  • EVA gasket
  • Neodymium magnet
  • Impedance control ring (aluminum)
  • Description

    The Visaton PAW 30 ND – 8 is a 12-inch bass-midwoofer that injects power and clarity into professional audio (PA) systems. Designed to conquer the demanding world of live music, this 8-ohm speaker is ideal for bands, DJs, and other audio professionals who need their music to be heard loud and clear.

    Highlights of the Visaton PAW 30 ND – 8

    • Octagonal die cast basket
    • Paper membrane
    • 75 mm voice coil for high power handling
    • Til voice coil former
    • Vented spider
    • Additional vented air gap (8 holes)
    • 10 mm t-yoke venting
    • M shape surround for high excursion
    • Connex spider
    • EVA gasket
    • Neodymium magnet
    • Impedance control ring (aluminum)

    Product details Visaton PAW 30 ND – 8

    Visaton PAW 30 ND – 8 Bass-midwoofer

    Built to endure the rigors of live performances, the PAW 30 ND – 8 boasts a sturdy octagonal die-cast basket and a paper membrane. This robust combination ensures the speaker can handle the bumps and knocks that come with frequent use. But don’t be fooled by its durability – this speaker packs a serious sonic punch. With a power handling of 400 watts, it delivers clear and powerful sound even in large venues. Additionally, the wide frequency response of the PAW 30 ND – 8 faithfully reproduces a broad range of sound, from deep bass tones to crisp mids, for a well-balanced and natural listening experience for your audience.

    The PAW 30 ND – 8 incorporates thoughtful design elements to optimize its performance. A vented spider and strategically placed air gap holes work together to efficiently dissipate heat, ensuring the speaker maintains optimal performance throughout a show. Additionally, the M-shaped surround allows the speaker cone to move a significant distance without distortion. This translates to clear and accurate sound reproduction at high volumes, ensuring your music reaches the audience exactly as intended. Overall, the Visaton PAW 30 ND – 8 is a reliable and powerful mid-woofer solution for professional audio applications. Its robust build, high power handling, wide frequency response, and well-designed features make it a great choice for bands, DJs, and audio professionals who demand clear and powerful sound for their audiences.

    Specifications

    Article number

    PAW 30 ND – 8
    EAN

    4007540030524
    Woofer Type
    Bass Midwoofer
    Nominal Diameter
    12“
    Power Handling (RMS)
    400 Watts
    Power Handling (max)
    600 Watts
    Impedance (Z)
    8 Ω
    Sensitivity (SPL at 1m / 2.83V)
    93 dB
    Frequency Response
    45-5500 Hz
    Voice Coil Diameter
    75 mm
    DC Resistance (Re)
    6.1 Ω
    Voice Coil Inductance (Le)
    0.55 mH
    Resonant Frequency (Fs)
    45 Hz
    Mechanical Q (Qms)
    7.63
    Electromagnetic Q (Qes)
    0.37
    Total Q (Qts)
    0.36
    Diaphragm Mass Inc. Airload (Mms)
    69 g
    Mechanical Compliance of Suspension (Cms)
    0.19 mm/N
    Surface Area of Cone (Sd)
    539 cm²
    BL Product (BL)
    17.6 Tm
    Compliance Equivalent Volume (Vas)
    78 Liters
    Maximum Linear Excursion (Xmax)
    +/−4 mm
    Overall Outside Diameter
    329 mm
    Overall Depth
    142 mm
    Baffle Cutout Diameter
    286 mm
    # Mounting Holes
    8
    Mounting Hole Diameter
    6.4 mm
