SB Acoustics RINJANI TX Black High-Gloss Tower Speaker Kit with TeXtreme drivers

€3,499.95

The SB Acoustics RINJANI TX is a premium 2.5-way floor-standing speaker kit that combines advanced TeXtreme® driver technology with a meticulously engineered crossover network to deliver exceptional audio performance.

Available on backorder

SKU: RINJANI-TX-Black-HG-Kit Categories: ,
Description

Highlights of the SB Acoustics RINJANI TX Black High-Gloss Tower Speaker Kit with TeXtreme Drivers

  • Equipped with dual 6½” SATORI MW16TX-8 TeXtreme® midwoofers and a 29mm SATORI TW29TXN-B-8 TeXtreme® tweeter for superior sound reproduction.
  • Innovative crossover design tailored for TeXtreme® drivers, enhancing natural and lifelike audio output.
  • Faceted baffle and 7° reclined cabinet design minimize high-frequency diffraction and ensure optimal time alignment.
  • Available in a premium black high-gloss finish for an elegant aesthetic.



Product details SB Acoustics RINJANI TX Black High-Gloss Tower Speaker Kit with TeXtreme Drivers

SB Acoustics RINJANI TX Tower Speaker Kit



The SB Acoustics RINJANI TX is a high-fidelity DIY speaker kit designed for audiophiles seeking top-tier performance. It utilizes TeXtreme® technology in both its midwoofers and tweeter, delivering a balanced and natural sound. The innovative crossover design has been completely revised for the TeXtreme® drivers, resulting in a very natural and true-to-life sound, with accurate and solid bass even at high listening levels. The RINJANI’s faceted baffle is specially designed to reduce high-frequency diffraction, yielding superb imaging qualities. The 7° reclined cabinet ensures good time alignment, resulting in sublime staging and pinpoint placement of instruments. The quality crossover resides in its own sealed chamber in the bottom of the speaker with a slanted divider to diminish standing waves. As an open-source kit, the RINJANI TX offers flexibility for enthusiasts to customize and build their dream speaker system while benefiting from SB Acoustics’ carefully developed plans and documentation.

Specifications

Article number RINJANI-TX-Black-HG-Kit
EAN 9507932924455
Nominal Diameter Woofers 6½", Tweeter 1"
Power Handling (RMS) Woofers 60 Watts each, Tweeter 80 Watts
Impedance (Z) Woofers 4 Ω, Tweeter 4 Ω
Voice Coil Diameter Woofers 36 mm, Tweeter 29 mm
DC Resistance (Re) Woofers 3.4 Ω, Tweeter 3.0 Ω
Voice Coil Inductance (Le) Woofers 0.15 mH, Tweeter 0.02 mH
Mechanical Q (Qms) Woofers 5.0. Tweeter 1.62
Electromagnetic Q (Qes) Woofers 0.29, Tweeter 0.65
Total Q (Qts) Woofers 0.27, Tweeter 0.46
Diaphragm Mass Inc. Airload (Mms) Woofers 12.6 g, Tweeter 0.51 g
Volume of Displacement (Vd) Woofers 119 cm², Tweeter 9.6 cm²
BL Product (BL) Woofers 5.2 Tm, Tweeters 3.1 Tm
Compliance Equivalent Volume (Vas) Woofers 48 Liters
Maximum Linear Excursion (Xmax) Woofers 12 mm (p-p), Tweeter 0.5 mm (p-p)
Overall Outside Diameter Wooofers 165 mm, Tweeter 103.8 mm
Overall Depth Woofers 86.1 mm, Tweeters 27.5 mm
Baffle Cutout Diameter Woofers 140 mm, Tweeter 70 mm
# Mounting Holes Woofers and Tweeter 6
Mounting Hole Diameter Woofers 4.3 mm. Tweeter 4.2 mm
Article number RINJANI-TX-Black-HG-Kit
EAN 9507932924455
Additional information
Nominal DiameterWoofers 6½”, Tweeter 1″
Power Handling (RMS)Woofers 60 Watts each, Tweeter 80 Watts
Impedance (Z)Woofers 4 Ω, Tweeter 4 Ω
Voice Coil DiameterWoofers 36 mm, Tweeter 29 mm
DC Resistance (Re)Woofers 3.4 Ω, Tweeter 3.0 Ω
Voice Coil Inductance (Le)Woofers 0.15 mH, Tweeter 0.02 mH
Mechanical Q (Qms)Woofers 5.0. Tweeter 1.62
Electromagnetic Q (Qes)Woofers 0.29, Tweeter 0.65
Total Q (Qts)Woofers 0.27, Tweeter 0.46
Diaphragm Mass Inc. Airload (Mms)Woofers 12.6 g, Tweeter 0.51 g
Volume of Displacement (Vd)Woofers 119 cm², Tweeter 9.6 cm²
BL Product (BL)Woofers 5.2 Tm, Tweeters 3.1 Tm
Compliance Equivalent Volume (Vas)Woofers 48 Liters
Maximum Linear Excursion (Xmax)Woofers 12 mm (p-p), Tweeter 0.5 mm (p-p)
Overall Outside DiameterWooofers 165 mm, Tweeter 103.8 mm
Overall DepthWoofers 86.1 mm, Tweeters 27.5 mm
Baffle Cutout DiameterWoofers 140 mm, Tweeter 70 mm
# Mounting HolesWoofers and Tweeter 6
Mounting Hole DiameterWoofers 4.3 mm. Tweeter 4.2 mm
