Visaton DL 25 25.4cm 100V Ceiling Speaker
€208.95
25 cm (10″) ceiling speaker equipped with a 13 cm coaxial driver.
2 in stock
Highlights
- For suspended ceilings in shops, private accommodation, bathrooms etc.
- For fitting in hollow ceilings, for music and speech in shops, at home, hotels etc.
- Ceiling-mounted speakers
- Public address applications
Product details
Visaton DL 25 25.4cm 100V Ceiling Speaker 8 Ohm
This ceiling speaker has four mounting clamps which make it easy and quick to install. The magnetic grilles covers the loudspeaker completely and can be removed with a simple step. Thanks to the 8 Ohm and 100 V taps, the ceiling speaker is versatile.
PRODUCT SPECIFICATIONS
|
Rated power |
20 watts |
|
Maximum power |
30 watts |
|
Nominal impedance Z |
8 ohms |
|
Frequency response |
90 – 20,000 Hz |
|
Mean sound pressure level |
90 dB |
|
Opening angle (-6 dB) |
70°/ 4000 Hz |
|
Resonance frequency fs |
150 Hz |
|
Cutout diameter |
212 mm |
|
Net weight |
2000 g |
|
Transformer matching |
20; 10; 5; 2.5 W |
|
Sound pressure level |
96 dB (1 W/1 m) at 4114 Hz |
|
Max. sound pressure level |
104.7 dB (30 W/1 m) |
|
Colour |
RAL 9010 |
|
Mounting depth |
150.5 mm |
|
Diameter |
245 mm |
|
Cutout diameter |
212 mm |
|
Temperature range |
-40 – 70 °C |
Visaton article code: 50168
Specifications
| Article number | DL 25 |
| EAN | 4007540501680 |
| Power Handling (RMS) | 20 Watts |
| Rated power | 20 watts |
| Maximum power | 30 watts |
| Nominal impedance Z | 8 ohms |
| Frequency response | 90 – 20,000 Hz |
| Mean sound pressure level | 90 dB |
| Opening angle (-6 dB) | 70°/ 4000 Hz |
| Resonance frequency fs | 150 Hz |
| Cutout diameter | 212 mm |
| Net weight | 2000 g |
| Transformer matching | 20; 10; 5; 2.5 W |
| Sound pressure level | 96 dB (1 W/1 m) at 4114 Hz |
| Max. sound pressure level | 104.7 dB (30 W/1 m) |
| Colour | RAL 9010 |
| Mounting depth | 150.5 mm |
| Diameter | 245 mm |
| Temperature range | -40 – 70 °C |
| Visaton article code | 50168 |
| Article number | DL 25 |
| EAN | 4007540501680 |
| Power Handling (RMS) | 20 Watts |
|---|---|
| Rated Power | 20 watts |
| Maximum power | 30 watts |
| Nominal impedance Z | 8 ohms |
| Frequency response | 90 – 20,000 Hz |
| Mean sound pressure level | 90 dB |
| Opening angle (-6 dB) | 70°/ 4000 Hz |
| Resonance frequency fs | 150 Hz |
| Cutout Diameter | 212 mm |
| Net Weight | 2000 g |
| Transformer matching | 20; 10; 5; 2.5 W |
| Sound pressure level | 96 dB (1 W/1 m) at 4114 Hz |
| Max. sound pressure level | 104.7 dB (30 W/1 m) |
| Color | RAL 9010 |
| Mounting depth | 150.5 mm |
| Diameter | 245 mm |
| Temperature range | -40 – 70 °C |
| Visaton article code | 50168 |
