CSS Criton 2TD-X MTM Speaker Kit with LD25X and Superior Crossover
€1,999.95
Discerning audiophiles seeking a top-tier DIY speaker project, look no further than the CSS Criton 2TD-X MTM Speaker Kit. This premium kit allows you to build your own high-fidelity tower speakers, boasting the best sound quality within the Criton lineup. This kit comes with the upgraded crossover design.
Available on backorder
SKU:
Criton-2TD-X-MTM-Kit-SUP
Categories: DIY Kits, DIY Speaker Kit
Description
Highlights
- Unmatched sound in the Criton lineup: The combination of powerful LDW7 woofers, the refined LD25X tweeter, and high-quality crossovers delivers exceptional sound quality. Users report a well-balanced soundscape with clear highs, detailed mids, and tight, deep bass.
- High output, low distortion: The dual woofers and upgraded design allow the speakers to handle high volumes without compromising clarity. This makes them perfect for larger rooms or those who enjoy listening to music at higher volumes.
- DIY construction: The kit offers significant savings compared to pre-built speakers. While assembly is considered user-friendly, some basic woodworking skills and tools are recommended.
- Superior Version
Product details
CSS Criton 2TD-X MTM Speaker Kit with LD25X and Superior Crossover
The key improvement lies in the upgraded tweeter. The 2TD-X features the LD25X tweeter, known for its detailed performance in the upper midrange and highs. This translates to a smoother and more nuanced sound experience compared to the standard 2TD.
Overall, the CSS Criton 2TD-X MTM Speaker Kit has exceptional sound quality and the satisfaction of a DIY project. The upgraded tweeter elevates the audio experience compared to the standard 2TD, making it the most refined speaker kit in the Criton series.
This kit includes:
- 2x CSS LD25X tweeters
- 4x CSS LDW7 woofers
- 6x 12 uF capacitors*
- 2x 1.5 mH inductors*
- 2x 0.30 mH inductors*
- 2x 8.0 Ohm resistors*
- 2x 2.0 Ohm resistors*
- 2x 1.0 Ohm resistors*
- 2x 3.0 Ohm resistors*
- 2x CSS SmartNode crossover boards*
- 2x pairs gold plated binding posts
- 4x 2″ diameter port tubes
- Screws
- Zip Ties
- Internal speaker wire
- Crossover hookup wire
- Eggcrate foam
*Please note this is for the Superior version. Go to here for standard crossover version (400 EUR cheaper).
Specifications
| Article number | Criton-2TD-X-MTM-Kit-SUP |
| EAN | 9503158763670 |
| Nominal Diameter | Bass-Midwoofer 7", Tweeter 1" |
| Power Handling (RMS) | Bass-Midwoofer 80 Watts each, Tweeter 75 Watts |
| Power Handling (max) | Bass-Midwoofer 200 Watts |
| Impedance (Z) | Bass-midwoofer 8 Ω, Tweeter 8 Ω |
| Sensitivity (SPL at 1m / 2.83V) | Bass-Midwoofer 86 dB, Tweeter 90 dB |
| Frequency Response | Bass-Midwoofer 30-4.500 Hz, Tweeter 2.000-22.000 Hz. |
| Voice Coil Diameter | Bass-Midwoofer 40 mm, Tweeter 27 mm |
| DC Resistance (Re) | Bass-Midwoofer 6.4 Ω, Tweeter 6.4 Ω |
| Voice Coil Inductance (Le) | Bass-Midwoofer 0.17 mH, Tweeter 0.07 mH |
| Resonant Frequency (Fs) | Bass-Midwoofer 30 Hz, Tweeter 865 Hz. |
| Mechanical Q (Qms) | Bass-Midwoofer 9, Tweeter 4.21 |
| Electromagnetic Q (Qes) | Bass-Midwoofer 0.39, Tweeter 1.85 |
| Total Q (Qts) | Bass-Midwoofer 0.37, Tweeter 1.28 |
| Surface Area of Cone (Sd) | Bass-Midwoofer 131 cm² |
| Article number | Criton-2TD-X-MTM-Kit-SUP |
| EAN | 9503158763670 |
Additional information
| Nominal Diameter | Bass-Midwoofer 7″, Tweeter 1″ |
|---|---|
| Power Handling (RMS) | Bass-Midwoofer 80 Watts each, Tweeter 75 Watts |
| Power Handling (max) | Bass-Midwoofer 200 Watts |
| Impedance (Z) | Bass-Midwoofer 8 Ω, Tweeter 8 Ω |
| Sensitivity (SPL at 1m / 2.83V) | Bass-Midwoofer 86 dB, Tweeter 90 dB |
| Frequency response | Bass-Midwoofer 30-4.500 Hz, Tweeter 2.000-22.000 Hz. |
| Voice Coil Diameter | Bass-Midwoofer 40 mm, Tweeter 27 mm |
| DC Resistance (Re) | Bass-Midwoofer 6.4 Ω, Tweeter 6.4 Ω |
| Voice Coil Inductance (Le) | Bass-Midwoofer 0.17 mH, Tweeter 0.07 mH |
| Resonant Frequency (Fs) | Bass-Midwoofer 30 Hz, Tweeter 865 Hz. |
| Mechanical Q (Qms) | Bass-Midwoofer 9, Tweeter 4.21 |
| Electromagnetic Q (Qes) | Bass-Midwoofer 0.39, Tweeter 1.85 |
| Total Q (Qts) | Bass-Midwoofer 0.37, Tweeter 1.28 |
| Surface Area of Cone (Sd) | Bass-Midwoofer 131 cm² |
