Dayton Audio DATS V3 Computer Based Audio Component Test System

Highlights

• Compact and sturdy aluminum housing
• Build in and easy accessible calibration resistor
• Features a linearity test that allows to analyse shifting parameters on different signal levels
• Higher output creates better signal to noise ratio and allows for higher accuracy.
• 30,000 data points from 1 Hz to 20 kHz allow high-resolution impedance response measurement
• Perfect for acquiring T/S parameters in a quick and easy manner
• Capable of acquiring Wright Model parameters (Kr, Xr, Ki, Xi) to be used in precision simulation

Product details

Dayton Audio DATS V3 Computer Based Audio Component Test System

The DATS V3 is the latest version of the audio test system from Dayton Audio. The computer based test and measurement system is easy to use and has many features to acquire the right data of your loudspeaker system.

The electroacoustic parameters of a speaker system are very valuable when achieving your design goals. The DATS helps you to measure speaker impedance and acquire the parameters in a quick and easy manner. Besides measuring loudspeaker parameters, the DATS is perfect for measuring the exact values of passive components like resistors, capacitors and inductors. You can even use the DATS to analyse complete (cabinet, crossover and drivers) loudspeaker systems.

Besides analyzing loudspeaker components and complete loudspeakers systems, the DATS can also be used as signal generator and oscilloscope for small signal analysis. Software features like ‘Rub and Buzz Test’ reveal flaws and can help you with quality control in your workshop.
