Mundorf H50-3,9 | 3,9 mH | 0,96 Ω | 3% | 24 AWG | MCoil Ferrite/Aronit DrumCore Coil

Highlights of the Mundorf H50-3,9

• 3.9 mH inductance with ±3% tolerance
• 0.96 Ohm DC resistance
• Ferrite/Aronit drum core construction
• OFC-Copper SolidCore conductor
• 0.20 mm², AWG 24, 0.50 mm wire

Product details Mundorf H50-3,9

Mundorf H50-3,9 3.9 mH MCoil Ferrite/Aronit DrumCore Coil 0.96 Ohm 3% 24 AWG

The Mundorf H50-3,9 is part of the MCoil H Ferrite/Aronit DrumCore series, designed for use in passive speaker crossover components. With an inductance value of 3.9 mH and a tight ±3% tolerance, it is suitable for builders who need predictable component values in crossover design, repair or upgrade work.

Its Ferrite/Aronit drum core construction keeps the coil compact while providing the required inductance value. The H50-3,9 measures Ø26 x H25 mm, making it practical for installations where crossover board space is limited.

The conductor is made from OFC-Copper SolidCore wire with a 0.20 mm² cross section, AWG 24 rating and 0.50 mm wire diameter. The coil has a DC resistance of 0.96 Ohm, giving you a clear electrical specification for integration with other passive coils and filter components.

A taped winding fixation and F2625 coil body provide a straightforward, stable construction for DIY and replacement use. The H50-3,9 is a precise Mundorf component for building consistent passive crossover networks.
