PRV Audio 6CX380-4 SLIM Coaxial Woofer
€87.95
The PRV Audio 6CX380-4 SLIM is a compact, high-performance professional coaxial driver designed for space-constrained audio installations without sacrificing clarity or power. Delivering impressive output with precise detail, it’s ideal for pro audio and custom automotive applications.
Available on backorder
Highlights of the PRV Audio 6CX380-4 SLIM
- Dual concentric design with 6.5″ woofer and 1″ high-frequency driver
- 380 Watts continuous program power handling at 4 Ohms
- Slim profile with only 2.76″ (70 mm) mounting depth
- Wide frequency response from 100 Hz to 20,000 Hz with 96 dB sensitivity
- Grill and screws included
Product details PRV Audio 6CX380-4 SLIM
PRV Audio 6CX380-4 SLIM Coaxial Driver
The PRV Audio 6CX380-4 SLIM is a precision-engineered coaxial speaker optimized for installations where depth is limited but performance is critical. Featuring a 6.5″ low-frequency driver paired with a 1″ high-frequency compression driver, it offers true point-source alignment and coherent sound reproduction across its wide 100 Hz to 20 kHz frequency range.
Built with a 1.5″ copper-clad aluminum wire (CCAW) voice coil on a Kapton former, the woofer delivers strong midbass performance and handles up to 380W of program power. The high-frequency section uses a Mylar diaphragm and 1″ CCAW voice coil for detailed treble and efficient output. Sensitivity is rated at 96 dB at 1W/1m, ensuring high output even with modest amplification.
The driver’s slim profile (2.76″ mounting depth) makes it a perfect solution for tight spaces in car audio, pro audio monitors, or portable sound systems. Its robust steel frame ensures long-term durability, while the integrated design minimizes phase issues and simplifies installation. With a recommended high-pass crossover of 120 Hz, it integrates smoothly into multi-way systems for clear, balanced sound reproduction.
Specifications
| Article number | 6CX380-4 SLIM |
| EAN | 810075523010 |
| Woofer Type | Coaxial |
| Nominal Diameter | 6.5"| 152 mm |
| Power Handling (RMS) | 380 Watts |
| Sensitivity (SPL at 1m / 2.83V) | 96 dB |
| Frequency Response | 100 – 20000 Hz |
| Voice Coil Diameter | 38 mm |
| DC Resistance (Re) | 3.6 Ω |
| Voice Coil Inductance (Le) | 0.113 mH |
| Resonant Frequency (Fs) | 111.7 Hz |
| Mechanical Q (Qms) | 8.6 |
| Electromagnetic Q (Qes) | 0.84 |
| Total Q (Qts) | 0.77 |
| Diaphragm Mass Inc. Airload (Mms) | 8.77 g |
| Moving Mass Of Diaphragm (Mmd) | 7.80 g |
| Surface Area of Cone (Sd) | 143 cm² |
| BL Product (BL) | 5.11 Tm |
| Compliance Equivalent Volume (Vas) | 6.61 L |
| Maximum Linear Excursion (Xmax) | 2.75 mm |
| Cone / Diaphragm Material | Mylar |
| Voice Coil Wire Material | Copper |
| Voice Coil Former | Kapton |
| Basket / Frame Material | Stamped Steel |
| Magnet Material | Ferrite |
| Overall Outside Diameter | 172 mm |
| Overall Depth | 98 mm |
| Baffle Cutout Diameter | 185.5 mm |
| # Mounting Holes | 4 |
| plus | Slim profile for tight space installations |
| min | Limited low-end frequency response |
| Article number | 6CX380-4 SLIM |
| EAN | 810075523010 |
| Woofer Type | Coaxial |
|---|---|
| Nominal Diameter | 6.5″| 152 mm |
| Power Handling (RMS) | 380 Watts |
| Sensitivity (SPL at 1m / 2.83V) | 96 dB |
| Frequency response | 100 – 20000 Hz |
| Voice Coil Diameter | 38 mm |
| DC Resistance (Re) | 3.6 Ω |
| Voice Coil Inductance (Le) | 0.113 mH |
| Resonant Frequency (Fs) | 111.7 Hz |
| Mechanical Q (Qms) | 8.6 |
| Electromagnetic Q (Qes) | 0.84 |
| Total Q (Qts) | 0.77 |
| Diaphragm Mass Inc. Airload (Mms) | 8.77 g |
| Moving Mass Of Diaphragm (Mmd) | 7.80 g |
| Surface Area of Cone (Sd) | 143 cm2 |
| BL Product (BL) | 5.11 Tm |
| Compliance Equivalent Volume (Vas) | 6.61 L |
| Maximum Linear Excursion (Xmax) | 2.75 mm |
| Cone / Diaphragm Material | Mylar |
| Voice Coil Wire Material | Copper |
| Voice Coil Former | Kapton |
| Basket / Frame Material | Stamped Steel |
| Magnet Material | Ferrite |
| Overall Outside Diameter | 172 mm |
| Overall Depth | 98 mm |
| Baffle Cutout Diameter | 185.5 mm |
| # Mounting Holes | 4 |
