REDCATT 181FCD 1.8″ Compression driver 8 ohms

Highlights of the REDCATT 181FCD

• 1.8″ high-frequency compression driver with 8 ohm impedance
• 109 dB sensitivity for efficient high-output performance
• 70 W AES, 140 W continuous and 280 W peak power handling
• FEM optimized ferrite magnetic structure
• Designed for larger speaker systems, 2-way PA tops, portable column PA and commercial installs

Product details REDCATT 181FCD

REDCATT 181FCD 1.8″ Compression Driver 8 Ohm

The REDCATT 181FCD is a high-performance HF compression driver developed for professional loudspeaker engineering. It is well suited to demanding horn-waveguide tweeter applications where controlled high-frequency output and strong efficiency are required.

Its ferrite motor uses an FEM optimized magnetic structure to provide a robust high-force BL field. This supports precise control of the diaphragm assembly and helps the driver deliver a clear, pleasant high-frequency sound character with extended frequency response.

With 109 dB sensitivity and power handling of 70 W AES, 140 W continuous and 280 W peak, the 181FCD is built for use in larger speaker systems. Recommended applications include 2-way PA tops, portable column PA systems and commercial install systems.

The driver features a plastic basket, ferrite magnet, four mounting holes, a 110 mm overall size, 62.83 mm depth from flange to rear and a net weight of 1.75 kg. These mechanical details make it practical to integrate into cabinet projects using compatible horns and waveguides.
