Audyn PLUS/22.0/08 | 22 µF | 2% | 800 V | Plus Capacitor
€69.95
High-end Audyn Plus 22µF Capacitor with Polypropylene foil for superior audio performance.
2 in stock
Highlights
- Induction-free and low-damping construction.
- Aluminum-plastic cup with tinned copper wire connections.
- Nominal voltages: 800V, Temperature range: -25°C to +70°C.
- Capacitance tolerance: ± 2%.
Product details
Audyn PLUS/22.0/08 | 22 µF | 2% | 800 V | Plus Capacitor
The Audyn Plus 22µF Capacitor is a high-end component designed for both passive and active audio circuits. It features a Polypropylene foil construction and two separate windings connected in series, resulting in an induction-free and low-damping setup. The capacitor is housed in an Aluminum-plastic cup and comes with tinned copper wire connections for enhanced conductivity. The Capacitor can operate within a temperature range of -25°C to +70°C and has a nominal voltage of 800V. It offers a capacitance tolerance of ± 2%, ensuring accurate performance under different operating conditions. Ideal for crossover components in film/foil capacitors category, this capacitor is a reliable addition to your audio system.
Specifications
| Article number | PLUS/22.0/08 |
| EAN | 8785256851850 |
| Capacitance (µF) | 22 µF |
| Voltage Rating | 800 V |
| Tolerance | 2% |
| Dimensions: Ø * L (mm) | 51 x 63 |
| Termination Style | Axial |
| Article number | PLUS/22.0/08 |
| EAN | 8785256851850 |
| Capacitance (µF) | 22 µF |
|---|---|
| Voltage Rating | 800 V |
| Tolerance | 2% |
| Dimensions: Ø * L (mm) | 51 x 63 |
| Termination Style | Axial |
