Jantzen Audio 001-0288 | 82 µF | 5% | 400 V | MKP Capacitor
€27.95
The Cross Cap, entry-level, MKP capacitor has got the best sonic quality and the best electrical peculiarity in its price class. These capacitors uses high quality foil, produced and metalized in the EU. They do not make any unpleasant distortion on sound and do not “colour” the sound.
Available on backorder
Highlights
- Capacitor foil: Metalized (ZnAl) polypropylene foil
- Dielectric insulation: Polypropylene film
- Terminal leads: Tinned 4N copper wire
Product details
Jantzen Audio 001-0288 | 82 µF | 5% | 400 V | MKP Capacitor
The Cross Cap offers great performance and quality, at a very reasonable price point. This is Jantzen entry level audiophile multipurpose capacitor. The Cross Cap is available in a very wide range of capacitance values. Made from high quality metalized polypropylene foil. Single foil (standard type MKP/PP foil) construction. The Cross Cap is virtually free of distortion and delivers a pleasant and rather neutral sonic profile. Cross Caps can be used as power supply capacitors in tube amplifiers. For upgrading coupling capacitors in amplifiers, we recommend the Jantzen Superior Z series.
Specifications: Voltage rating: 400 VDC / 250 VAC • Working Temperature Range: -40C to + 85C • Capacitance tolerance: +/- 5%.
Specifications
| Article number | 001-0288 |
| EAN | 8785256839988 |
| Capacitance (µF) | 82 µF |
| Voltage Rating | 400 V |
| Tolerance | 5% |
| Dimensions: Ø * L (mm) | 54 x 58 |
| Termination Style | Axial |
| Working Temperature Range | -40C to + 85C |
| Capacitance tolerance | +/- 5%. |
| Article number | 001-0288 |
| EAN | 8785256839988 |
| Capacitance (µF) | 82 µF |
|---|---|
| Voltage Rating | 400 V |
| Tolerance | 5% |
| Dimensions: Ø * L (mm) | 54 x 58 |
| Termination Style | Axial |
| Working Temperature Range | -40C to + 85C |
| Capacitance tolerance | +/- 5%. |
