Sure Electronics AA-AB41164 Analog To I2S Decode Board Stereo Audio DAC ADC A2D-PCM1822
€22.45
The ASCM-A2D (AA-AB41164) from Sure Electronics is an Analog to I2S decode board designed for high-quality audio applications. Featuring the PCM1822 ADC, it supports both differential and single-ended inputs for versatile audio signal processing.
Available on backorder
Highlights of the Sure Electronics ASCM-A2D
- Two-channel simultaneous sampling
- Support for single-ended and differential line inputs
- Master and slave mode selection for audio bus interface
- Operating temperature range: -20°C to 65°C
Product details Sure Electronics ASCM-A2D
Sure Electronics ASCM-A2D Audio ADC Module
The ASCM-A2D is an audio analog-to-digital converter (ADC) module featuring the PCM1822. It offers simultaneous sampling of two analog channels, supporting both single-ended and differential signals. The module can operate in both master and slave modes, making it highly adaptable for various audio processing needs. It accepts a wide power supply range of 6V to 24V, ensuring compatibility with different systems. Designed for DIY and professional audio applications, it delivers excellent performance with low total harmonic distortion and high signal-to-noise ratio.
Specifications
| Article number | AA-AB41164 |
| EAN | 6959687301693 |
| DAC Chipset | PCM1822 analog to digital I2S |
| Inputs | analog-to-digital module: Differential (JST PH-4) and Single-Ended (JST PH-5) |
| Outputs | Digital output I2S (JST PH-6) |
| THD(+N) | 0.00047% |
| Dynamic Range | 111 dB |
| SNR | 119 dB |
| Supported file formats | Analog to I2S |
| Processing resolution & sample rate | Typ. 48/96, 192 Khz max Output I2S 44.1-48/96 Khz. 24 bit |
| Power requirements | DC 6 – 24 Volt |
| Dimensions | W 76 x H 12 x D 50.8 mm 3 x 0.47 x 2 " |
| Weight | 21 g |
| plus | Designed to enable the sampling two analog channels simultaneously in a digital signal (I2S) |
| Article number | AA-AB41164 |
| EAN | 6959687301693 |
| DAC Chipset | PCM1822 analog to digital I2S |
|---|---|
| Inputs | analog-to-digital module: Differential (JST PH-4) and Single-Ended (JST PH-5) |
| Outputs | Digital output I2S (JST PH-6) |
| THD+N | 0.00047% |
| Dynamic Range | 111 dB |
| SNR | 119 dB |
| Supported file formats | Analog to I2S |
| Processing resolution & sample rate | Typ. 48/96, 192 Khz max Output I2S 44.1-48/96 Khz. 24 bit |
| Power Requirements | DC 6 – 24 Volt |
| Dimensions | W 76 x H 12 x D 50.8 mm 3 x 0.47 x 2 “ |
| Weight | 21 g |
