Pressfit Speaker Grill Guides

Highlights

• Offers gentle friction-based holding power
• Used with grills as thin as 6,4mm
• Set includes 1 male and 1 female pieces

Product details

Pressfit Speaker Grill Guides Pair

Contemporary press-fit grill guides for attaching grills to cabinets. These do not “snap-in” like conventional ball and socket designs, but instead offer gentle friction-based holding power. This means that even if the guide is not inserted all the way, it will still hold your grill in place. To use, simply drill a 5,6mm hole for the pin side and an 8,7mm hole for the socket side. Can be used with grills as thin as 6,4mm. Set includes 1 male and 1 female pieces. Overall length of male is 17,5mm, overall length of socket is 11,9mm. Flange for both male and socket is 12,7mm.
