PRV Audio 6MR500CF-NDY-4 Neodymium Bass-midwoofer Pair
€374.95
The PRV Audio 6MR500CF-NDY-4 is a lightweight 8″ midrange driver built for high-output, high-efficiency systems. Designed with a water-resistant carbon fiber cone and a neodymium magnet, it delivers detailed sound and rugged performance in a compact format.
2 in stock
Highlights of the PRV Audio 6MR500CF-NDY-4 Pair
- Lightweight neodymium magnet for reduced weight and high efficiency
- 250 Watts continuous power handling with 96 dB sensitivity
- Water-resistant carbon fiber cone for durability in demanding environments
- Frequency response from 95 Hz to 11,000 Hz for extended midrange clarity
- Including grilles and screws for easy installation
Product details PRV Audio 6MR500CF-NDY-4 Pair
PRV Audio 6MR500CF-NDY-4 6″ Professional Mid Range Driver Pair
The PRV Audio 6MR500CF-NDY-4 is engineered for midrange clarity and lightweight performance. With its 4-ohm impedance and 2″ CCAW voice coil, it handles 250 Watts RMS and 500 Watts program power, offering excellent thermal performance and transient response. Its carbon fiber cone is not only water-resistant but also provides improved stiffness and reduced distortion. Combined with a stamped steel frame and neodymium magnet structure, the result is a powerful and compact unit weighing just 1.75 kg, making it ideal for use in car audio, portable PA systems, and custom enclosures.
With a sensitivity of 96 dB and a frequency response ranging from 95 Hz to 11,000 Hz, the 6MR500CF-NDY-4 delivers punchy mids and clear vocals. The mechanical design includes a mounting depth of 83.5 mm and a baffle cutout diameter of 166.5 mm, ensuring flexible integration across many enclosure types.
Sold in pairs with grilles and screws for easy installation
Specifications
| Article number | 6MR500CF-NDY-4 |
| EAN | 619620087577 |
| Woofer Series | PRV Neodymium series |
| Woofer Type | Midrange |
| Nominal Diameter | 6" | 152 mm |
| Power Handling (RMS) | 500 Watts |
| Sensitivity (SPL at 1m / 2.83V) | 96 dB |
| Frequency Response | 95 – 11000 Hz |
| Voice Coil Diameter | 50.8 mm |
| DC Resistance (Re) | 3.3 Ω |
| Voice Coil Inductance (Le) | 0.210mH |
| Resonant Frequency (Fs) | 85.2 Hz |
| Mechanical Q (Qms) | 11.1 |
| Electromagnetic Q (Qes) | 0.24 |
| Total Q (Qts) | 0.24 |
| Diaphragm Mass Inc. Airload (Mms) | 16.36 g |
| Surface Area of Cone (Sd) | 143 cm² |
| BL Product (BL) | 10.93 Tm |
| Compliance Equivalent Volume (Vas) | 6.1 L |
| Maximum Linear Excursion (Xmax) | 3.25 mm |
| Cone / Diaphragm Material | Carbon fiber cone |
| Voice Coil Wire Material | CCAW |
| Voice Coil Former | Kapton |
| Basket / Frame Material | Stamped Steel |
| Magnet Material | Neodymium |
| Overall Outside Diameter | 166.5 mm |
| Overall Depth | 83.5 mm |
| Baffle Cutout Diameter | 145.5 mm |
| Article number | 6MR500CF-NDY-4 |
| EAN | 619620087577 |
| Woofer Series | PRV Neodymium series |
|---|---|
| Woofer Type | Midrange |
| Nominal Diameter | 6″ | 152 mm |
| Power Handling (RMS) | 500 Watts |
| Sensitivity (SPL at 1m / 2.83V) | 96 dB |
| Frequency response | 95 – 11000 Hz |
| Voice Coil Diameter | 50.8 mm |
| DC Resistance (Re) | 3.3 Ω |
| Voice Coil Inductance (Le) | 0.210mH |
| Resonant Frequency (Fs) | 85.2 Hz |
| Mechanical Q (Qms) | 11.1 |
| Electromagnetic Q (Qes) | 0.24 |
| Total Q (Qts) | 0.24 |
| Diaphragm Mass Inc. Airload (Mms) | 16.36 g |
| Surface Area of Cone (Sd) | 143 cm2 |
| BL Product (BL) | 10.93 Tm |
| Compliance Equivalent Volume (Vas) | 6.1 L |
| Maximum Linear Excursion (Xmax) | 3.25 mm |
| Cone / Diaphragm Material | Carbon fiber cone |
| Voice Coil Wire Material | CCAW |
| Voice Coil Former | Kapton |
| Basket / Frame Material | Stamped Steel |
| Magnet Material | Neodymium |
| Overall Outside Diameter | 166.5 mm |
| Overall Depth | 83.5 mm |
| Baffle Cutout Diameter | 145.5 mm |
