SB Acoustics SB21SDCN-C000-4 Dome Tweeter
€39.95
SB Acoustics SB21SDCN-C000-4 3/4″ Fabric Dome Tweeter
2 in stock
Description
Highlights
- Non-reflective rear chamber with optimized damping for improved dynamics.
- Flow optimized vented pole piece for optimum coupling to rear chamber.
- CCAW voice coil for low moving mass.
- Long life silver lead wires.
- Low resonance frequency.
Product details
Large surround dome for increased acoustic output. Dual balanced compression chamber for improved dynamics. Copper cap for reduced voice coil inductance and minimum phase shift. Saturation controlled motor system for low distortion.
Specifications
| Article number | SB21SDCN-C000-4 |
| EAN | 8785256843800 |
| Tweeter Type | Dome Tweeter |
| Cone / Dome Diameter | 19 mm | 3/4" |
| Power Handling (RMS) | 40 Watts |
| Impedance (Z) | 4 Ω |
| Sensitivity (SPL at 1m / 2.83V) | 90 dB |
| Resonant Frequency (Fs) | 850 Hz |
| Mechanical Q (Qms) | 2.44 |
| Electromagnetic Q (Qes) | 2.45 |
| Total Q (Qts) | 1.22 |
| Article number | SB21SDCN-C000-4 |
| EAN | 8785256843800 |
Additional information
| Tweeter Type | Dome tweeter |
|---|---|
| Cone / Dome Diameter | 19 mm | 3/4″ |
| Power Handling (RMS) | 40 Watts |
| Impedance (Z) | 4 Ω |
| Sensitivity (SPL at 1m / 2.83V) | 90 dB |
| Resonant Frequency (Fs) | 850 Hz |
| Mechanical Q (Qms) | 2.44 |
| Electromagnetic Q (Qes) | 2.45 |
| Total Q (Qts) | 1.22 |
