Monacor SPH-8M 8’’ Woofer
€124.95
Well designed woofer with balanced T/S parameters making it very well-suited for both bass-reflex and closed speaker systems.
1 in stock
Description
Highlights
- Broad frequency range
- Dampened low-resonance polypropylene cone
- Robust diecast aluminium basket
- Magnet system with drilled pole core
Product details
Monacor SPH-8M 8’’ Woofer
The Monacor SPH-8M is a Hi-fi bass speaker of excellent workmanship. It features a dampened low-resonance polypropylene cone, a robust diecast aluminium basket of an elegant design with 6-hole screw connection and a magnet system with drilled pole core. The balanced T/S parameters make it very well-suited for both bass-reflex and closed speaker systems.
Specifications
| Article number | SPH-8M |
| EAN | 4007754221299 |
| Woofer Type | Woofer |
| Nominal Diameter | 8'' |
| Power Handling (RMS) | 100 Watts |
| Power Handling (max) | 150 Watts |
| Impedance (Z) | 8 Ohms |
| Sensitivity (SPL at 1m / 2.83V) | 89 dB |
| Frequency Response | 35-2,500 Hz |
| Voice Coil Diameter | 38 mm |
| Magnet Weight | 790 g |
| DC Resistance (Re) | 6.5 Ohms |
| Voice Coil Inductance (Le) | 0.78 mH |
| Resonant Frequency (Fs) | 35 Hz |
| Mechanical Q (Qms) | 2.26 |
| Electromagnetic Q (Qes) | 0.50 |
| Total Q (Qts) | 0.41 |
| Diaphragm Mass Inc. Airload (Mms) | 27 g |
| Mechanical Compliance of Suspension (Cms) | 0.71 mm/N |
| Surface Area of Cone (Sd) | 240 cm2 |
| BL Product (BL) | 9.01 Tm |
| Compliance Equivalent Volume (Vas) | 44 l |
| Maximum Linear Excursion (Xmax) | 4.5 mm |
| Cone / Diaphragm Material | Polypropylene |
| Surround Material | Rubber |
| Voice Coil Wire Material | Copper |
| Voice Coil Former | Aluminum |
| Basket / Frame Material | Aluminum |
| Magnet Material | Ferrite |
| Overall Outside Diameter | 222 mm |
| Overall Depth | 97 mm |
| Baffle Cutout Diameter | 180 mm |
| # Mounting Holes | 6 |
| Mounting Hole Diameter | 5.5 mm |
| Article number | SPH-8M |
| EAN | 4007754221299 |
Additional information
| Woofer Type | Woofer |
|---|---|
| Nominal Diameter | 8” |
| Power Handling (RMS) | 100 Watts |
| Power Handling (max) | 150 Watts |
| Impedance (Z) | 8 ohms |
| Sensitivity (SPL at 1m / 2.83V) | 89 dB |
| Frequency response | 35-2,500 Hz |
| Voice Coil Diameter | 38 mm |
| Magnet Weight | 790 g |
| DC Resistance (Re) | 6.5 ohms |
| Voice Coil Inductance (Le) | 0.78 mH |
| Resonant Frequency (Fs) | 35 Hz |
| Mechanical Q (Qms) | 2.26 |
| Electromagnetic Q (Qes) | 0.50 |
| Total Q (Qts) | 0.41 |
| Diaphragm Mass Inc. Airload (Mms) | 27 g |
| Mechanical Compliance of Suspension (Cms) | 0.71 mm/N |
| Surface Area of Cone (Sd) | 240 cm2 |
| BL Product (BL) | 9.01 Tm |
| Compliance Equivalent Volume (Vas) | 44 l |
| Maximum Linear Excursion (Xmax) | 4.5 mm |
| Cone / Diaphragm Material | Polypropylene |
| Surround Material | Rubber |
| Voice Coil Wire Material | Copper |
| Voice Coil Former | Aluminum |
| Basket / Frame Material | Aluminum |
| Magnet Material | Ferrite |
| Overall Outside Diameter | 222 mm |
| Overall Depth | 97 mm |
| Baffle Cutout Diameter | 180 mm |
| # Mounting Holes | 6 |
| Mounting Hole Diameter | 5.5 mm |
