Peerless by Tymphany BC25SC55-04 Dome Tweeter
€22.95
The smooth-sounding BC25 SC55-04 1″ compact soft dome tweeter from Tymphany features high output and response past 30 kHz thanks to a high-strength neodymium motor with heatsink fins.
288 in stock
Description
Highlights of the Peerless BC25SC55-04 Dome Tweeter
- Sensitivity (SPL at 1m / 2.83V): 93.2 dB
- Resonant Frequency (Fs): 1400 Hz
- Neodymium magnet for high output and compact size
- Truncated faceplate permits optimal driver spacing
- Rear heatsink increases thermal management
- Frequency response extends past 30 kHz
Product details Peerless BC25SC55-04 Dome Tweeter
Peerless by Tymphany BC25SC55-04 1″ Square Frame Tweeter
This BC family tweeter features a 4 ohm 25 mm voice coil, a damped fabric dome for smooth frequency response performance, and ferrofluid in the gap of the neodymium magnet motor, providing enhanced cooling of the voice coil. The tweeter comes with a compact faceplate with recessed mounting holes, complete with sealing gasket which helps in reducing vibration between baffle and driver. A finned heat sink has been added for improved power handling.
Specifications
| Article number | BC25SC55-04 |
| EAN | 0844632083730 |
| Tweeter Type | Soft Dome |
| Tweeter Series | BC Series |
| Cone / Dome Diameter | 25 mm | 1" |
| Power Handling (RMS) | 7 Watts |
| Impedance (Z) | 4 Ω |
| Sensitivity (SPL at 1m / 2.83V) | 93.2 dB |
| Frequency Response | 1.500 – 20.000 Hz |
| Resonant Frequency (Fs) | 1.400 Hz |
| DC Resistance (Re) | 3 Ω |
| Voice Coil Inductance (Le) | 0.026 mH |
| Mechanical Q (Qms) | 3.6 |
| Electromagnetic Q (Qes) | 2.07 |
| Total Q (Qts) | 1.3 |
| Overall Outside Diameter | 70 x 55 mm |
| Cutout Diameter | 47 mm |
| Depth | 29.55 mm |
| Diaphragm Material | Silk |
| plus | Truncated faceplate |
| min | Limited capacity |
| Article number | BC25SC55-04 |
| EAN | 0844632083730 |
Additional information
| Tweeter Type | Soft Dome |
|---|---|
| Tweeter Series | BC Series |
| Cone / Dome Diameter | 25 mm | 1″ |
| Power Handling (RMS) | 7 Watts |
| Impedance (Z) | 4 Ω |
| Sensitivity (SPL at 1m / 2.83V) | 93.2 dB |
| Frequency response | 1.500 – 20.000 Hz |
| Resonant Frequency (Fs) | 1.400 Hz |
| DC Resistance (Re) | 3 Ω |
| Voice Coil Inductance (Le) | 0.026 mH |
| Mechanical Q (Qms) | 3.6 |
| Electromagnetic Q (Qes) | 2.07 |
| Total Q (Qts) | 1.3 |
| Overall Outside Diameter | 70 x 55 mm |
| Cutout Diameter | 47 mm |
| Depth | 29.55 mm |
| Diaphragm Material | Silk |
