SB Audience BIANCO-10MW200 Mid-range Woofer
€82.45
SB Audience is spawned from the heavyweight manufacturing of Sinar Baja Electric Indonesia and has serviced well known brands in the PRO audio industry for decades with in house engineering and manufacturing.
Available on backorder
Highlights
- Proprietary cone paper material with linter pulp
- 2.4″ voice coil with APC (Advanced Polymer Coating)
- Vented pole piece for reduced compression
- Minimum damping fiber glass voice coil former
- Weather-proof coated cone paper
- Long life silver lead wires
Product Details
SB Audience BIANCO-10MW200 Mid-range Woofer
SB Audience is spawned from the heavyweight manufacturing of Sinar Baja Electric Indonesia, with well over 40 years of experience in development and manufacturing of solutions for professional OEM drivers, and has serviced well known brands in the PRO audio industry for decades with in-house engineering and manufacturing.
There are three categories within our standard product range: Bianco, achieves good performance at the most reasonable cost. Rosso, aims at high performance at an attractive price, and Nero is our higher performance line still achieving exceptional price performance ratio.
Specifications
| Article number | BIANCO-10MW200 |
| EAN | 8785256846269 |
| Woofer Series | SB Audience Bianco series |
| Woofer Type | Mid-range |
| Nominal Diameter | 10” |
| Power Handling (RMS) | 250 Watts |
| Power Handling (max) | 500 W |
| Impedance (Z) | 8 Ohm |
| Sensitivity (SPL at 1m / 2.83V) | 98 dB |
| Frequency Response | 56 – 7100 Hz |
| Voice Coil Diameter | 60.5 mm (2.4 in) |
| DC Resistance (Re) | 5.7 Ohm |
| Voice Coil Inductance (Le) | 0.6 mH |
| Resonant Frequency (Fs) | 56 Hz |
| Mechanical Q (Qms) | 2.28 |
| Electromagnetic Q (Qes) | 0.43 |
| Total Q (Qts) | 0.36 |
| Diaphragm Mass Inc. Airload (Mms) | 38 gr |
| Mechanical Compliance of Suspension (Cms) | 0.22 mm/N |
| Surface Area of Cone (Sd) | 366.4cm² |
| BL Product (BL) | 13 Tm |
| Compliance Equivalent Volume (Vas) | 41liters |
| Maximum Linear Excursion (Xmax) | 6.7 mm |
| Driver's Mechanical Losses (Rms) | 0.22 mm/N |
| Basket / Frame Material | Stamped steel |
| Magnet Material | Ferrite |
| Overall Outside Diameter | 257 mm (10.11 in) |
| Baffle Cutout Diameter | 230 mm (9.05 in) |
| Bolt Circle Diameter | 245 mm (9.65 in) |
| Article number | BIANCO-10MW200 |
| EAN | 8785256846269 |
| Woofer Series | SB Audience Bianco series |
|---|---|
| Woofer Type | Mid-range |
| Nominal Diameter | 10” |
| Power Handling (RMS) | 250 Watts |
| Power Handling (max) | 500 W |
| Impedance (Z) | 8 Ohm |
| Sensitivity (SPL at 1m / 2.83V) | 98 dB |
| Frequency response | 56 – 7100 Hz |
| Voice Coil Diameter | 60.5 mm (2.4 in) |
| DC Resistance (Re) | 5.7 Ohm |
| Voice Coil Inductance (Le) | 0.6 mH |
| Resonant Frequency (Fs) | 56 Hz |
| Mechanical Q (Qms) | 2.28 |
| Electromagnetic Q (Qes) | 0.43 |
| Total Q (Qts) | 0.36 |
| Diaphragm Mass Inc. Airload (Mms) | 38 gr |
| Mechanical Compliance of Suspension (Cms) | 0.22 mm/N |
| Surface Area of Cone (Sd) | 366.4cm² |
| BL Product (BL) | 13 Tm |
| Compliance Equivalent Volume (Vas) | 41liters |
| Maximum Linear Excursion (Xmax) | 6.7 mm |
| Driver's Mechanical Losses (Rms) | 0.22 mm/N |
| Basket / Frame Material | Stamped Steel |
| Magnet Material | Ferrite |
| Overall Outside Diameter | 257 mm (10.11 in) |
| Baffle Cutout Diameter | 230 mm (9.05 in) |
| Bolt Circle Diameter | 245 mm (9.65 in) |
