Visaton W 100 X Bass-midwoofer
€59.95
Introducing the VISATON W 100 X, a high-performance 10 cm (4”) woofer designed for optimal audio quality and versatility. Its compact size and advanced features make it an excellent choice for both hi-fi systems and industrial applications.
2 in stock
Highlights of the VISATON W 100 X
- Low resonant frequency for superior bass performance
- Wide and elastic rubber surround for large excursion
- 2×4 Ohm dual voice coil for flexible impedance options
- Easy-to-install and visually appealing metal basket
Product details VISATON W 100 X
VISATON W 100 X Subwoofer
The VISATON W 100 X is a 10 cm (4”) woofer featuring a low resonant frequency and a compact design. Its wide and elastic rubber surround enables a large excursion, ensuring deep and accurate bass reproduction. The dual 2×4 Ohm voice coil allows for various impedance configurations (2, 4, and 8 Ohms), making it suitable for different audio setups, including stereo connections through car radio rear channels. The W 100 X’s metal basket is not only easy to install but also adds a touch of aesthetic appeal, making it a versatile subwoofer for high-fidelity audio and industrial use.
Specifications
| Article number | W 100 X |
| EAN | 4007540090498 |
| Woofer Type | Woofer |
| Nominal Diameter | 4“ |
| Power Handling (RMS) | 40 Watts |
| Impedance (Z) | 2,4 and 8 Ω (2 x 4 Ω) |
| Sensitivity (SPL at 1m / 2.83V) | 81 dB |
| Frequency Response | 45-12.000 Hz |
| Voice Coil Diameter | 26 mm |
| DC Resistance (Re) | 3.6, 7.2 and 1.8 Ω |
| Voice Coil Inductance (Le) | (1) 0.46 mH/(2) 1.49 mH/(3) 0.41 mH |
| Resonant Frequency (Fs) | 63 Hz |
| Mechanical Q (Qms) | (1) 3.17/(2) 3.33/(3) 2.74 |
| Electromagnetic Q (Qes) | (1) 0.95/(2) 0.48/(3) 0.43 |
| Total Q (Qts) | (1) 0.73/(2) 0.42/(3) 0.37 |
| Diaphragm Mass Inc. Airload (Mms) | 10.4 g |
| Surface Area of Cone (Sd) | 51.5 cm² |
| BL Product (BL) | (1) 3.02 Tm/(2) 7.93 Tm/(3) 3.75 Tm |
| Compliance Equivalent Volume (Vas) | (1) 2.63 l(2) 2.24 l(3) 2.89 liters |
| Maximum Linear Excursion (Xmax) | 7.5 mm |
| Overall Outside Diameter | 116 mm |
| Overall Depth | 61 mm |
| Baffle Cutout Diameter | 97 mm |
| # Mounting Holes | 4 |
| Mounting Hole Diameter | 4.4 mm |
