Volt Loudspeakers BM1651 6.5” Bass-midwoofer 8 ohm
€199.95
The Volt Loudspeakers BM1651 is a high-performance 6.5″ bass-midwoofer designed for audiophiles seeking minimal coloration and low distortion across a wide frequency range. This driver is particularly suited for compact monitors and 2-way systems, offering superb bass performance with excellent midrange extension.
2 in stock
Highlights of the Volt Loudspeakers BM1651 Bass-midwoofer
- 6.5″ critically doped plastic HIPS cone
- Symmetrical field magnet system with extended pole piece
- Mirrored double rear suspensions for transient stability
- Diecast aluminum vented chassis for enhanced cooling
Product details of the Volt Loudspeakers BM1651 Bass-midwoofer
Volt Loudspeakers BM1651 Bass-midwoofer
The BM1651 features a 6.5″ critically doped plastic HIPS cone, optimized for bass and midrange applications that require minimal coloration and low distortion. Its symmetrical field magnet system includes an extended pole piece, providing large linear excursion capabilities. This design is complemented by mirrored double rear suspensions, ensuring transient stability even at high drive levels. The driver’s Thiele-Small parameters are tuned for relatively small enclosures, which helps achieve a balanced bass performance that pairs well with its extended midband, making it ideal for high-fidelity 2-way systems.
The diecast aluminum chassis of the BM1651 is vented below the suspensions, increasing airflow for better cooling of the voice coil and magnet. This enhances the driver’s durability and performance under demanding conditions. The BM1651 operates within a frequency range of 50 to 3000 Hz, with a sensitivity of 88 dB/W/m and a power handling capacity of 100W AES.
Specifications
| Article number | BM1651 |
| EAN | 9505189583234 |
| Woofer Type | Bass-Midwoofer |
| Nominal Diameter | 6.5" |
| Power Handling (RMS) | 100 Watts |
| Impedance (Z) | 8 Ω |
| Sensitivity (SPL at 1m / 2.83V) | 88 dB |
| Frequency Response | 50 – 3000 Hz |
| Voice Coil Diameter | 38 mm |
| DC Resistance (Re) | 5.5 Ω |
| Voice Coil Inductance (Le) | 1.20 mH |
| Resonant Frequency (Fs) | 30 Hz |
| Mechanical Q (Qms) | 4.12 |
| Electromagnetic Q (Qes) | 0.26 |
| Total Q (Qts) | 0.24 |
| Diaphragm Mass Inc. Airload (Mms) | 25 g |
| Mechanical Compliance of Suspension (Cms) | 1.23 mm/N |
| Surface Area of Cone (Sd) | 153.94 cm² |
| Volume of Displacement (Vd) | 96.98 cm3 |
| BL Product (BL) | 9.8 N/A |
| Compliance Equivalent Volume (Vas) | 40.75 Litres |
| Maximum Linear Excursion (Xmax) | 6.3 mm |
| Basket / Frame Material | Diecast Aluminium |
| Overall Outside Diameter | 189 mm |
| Overall Depth | 90 mm |
| Baffle Cutout Diameter | 160 mm |
| # Mounting Holes | 4 |
| Mounting Hole Diameter | 5.2 mm |
| plus | Doped HIPS Cone |
| Article number | BM1651 |
| EAN | 9505189583234 |
| Woofer Type | Bass-Midwoofer |
|---|---|
| Nominal Diameter | 6.5″ |
| Power Handling (RMS) | 100 Watts |
| Impedance (Z) | 8 Ω |
| Sensitivity (SPL at 1m / 2.83V) | 88 dB |
| Frequency response | 50 – 3000 Hz |
| Voice Coil Diameter | 38 mm |
| DC Resistance (Re) | 5.5 Ω |
| Voice Coil Inductance (Le) | 1.20 mH |
| Resonant Frequency (Fs) | 30 Hz |
| Mechanical Q (Qms) | 4.12 |
| Electromagnetic Q (Qes) | 0.26 |
| Total Q (Qts) | 0.24 |
| Diaphragm Mass Inc. Airload (Mms) | 25 g |
| Mechanical Compliance of Suspension (Cms) | 1.23 mm/N |
| Surface Area of Cone (Sd) | 153.94 cm² |
| Volume of Displacement (Vd) | 96.98 cm3 |
| BL Product (BL) | 9.8 N/A |
| Compliance Equivalent Volume (Vas) | 40.75 Litres |
| Maximum Linear Excursion (Xmax) | 6.3 mm |
| Basket / Frame Material | Diecast Aluminium |
| Overall Outside Diameter | 189 mm |
| Overall Depth | 90 mm |
| Baffle Cutout Diameter | 160 mm |
| # Mounting Holes | 4 |
| Mounting Hole Diameter | 5.2 mm |
