Dayton Audio PA380-8 15″ Pro Woofer
€177.45
Dayton Audio PA Series Pro Woofers are a great upgrade for musical instrument or sound reinforcement cabinets, and also excel in custom-built speaker systems.
6 in stock
Description
Highlights
- Strong, low-mass carbon fiber impregnated paper cone
- I-beam rolled edge 1.5 mm steel frame
- Low distortion motor system w/copper cap
- Powerful 80 oz. ceramic ferrite magnet
- Vented pole piece/vented voice coil gap improve thermal management
- Black motor parts and black polyimide voice coil former dissipate heat
- Bumped back plate for unrestricted excursion
Product details
Dayton Audio PA380-8 15″ Pro Woofer
The Dayton Audio PA380-8 15″ PA Series Pro Woofer is a powerful upgrade for guitar, bass guitar or sound reinforcement cabinets. The PA380-8 also excels in custom-built speaker system cabinets. High power handling, smooth response, low distortion, deep punchy bass, and rugged reliability are the features that set PA Series woofers apart from other drivers – premium performance, but value priced.
Specifications
| Article number | PA380-8 |
| EAN | 0844632084249 |
| Woofer Series | Dayton Audio PA series |
| Woofer Type | Midwoofer |
| Nominal Diameter | 15" |
| Power Handling (RMS) | 500 Watts |
| Power Handling (max) | 1000 watts |
| Impedance (Z) | 8 ohms |
| Sensitivity (SPL at 1m / 2.83V) | 96.1 dB |
| Frequency Response | 28 – 3,500 Hz |
| Voice Coil Diameter | 76 mm |
| Magnet Weight | 80 oz. |
| DC Resistance (Re) | 6.3 ohms |
| Voice Coil Inductance (Le) | 4.12 mH @ 1 kHz |
| Resonant Frequency (Fs) | 31.6 Hz |
| Mechanical Q (Qms) | 12.20 |
| Electromagnetic Q (Qes) | 0.27 |
| Total Q (Qts) | 0.27 |
| Diaphragm Mass Inc. Airload (Mms) | 147g |
| Mechanical Compliance of Suspension (Cms) | 0.17 mm/N |
| Surface Area of Cone (Sd) | 845.0 cm² |
| Volume of Displacement (Vd) | 422.5 cm³ |
| BL Product (BL) | 25.8 Tm |
| Compliance Equivalent Volume (Vas) | 175 liters |
| Maximum Linear Excursion (Xmax) | 5 mm |
| Cone / Diaphragm Material | Paper / Carbon Fiber Cone |
| Surround Material | Cloth |
| Voice Coil Wire Material | Copper |
| Voice Coil Former | Kapton® / Polyimide |
| Basket / Frame Material | Steel |
| Magnet Material | Ferrite |
| Overall Outside Diameter | 380 mm |
| Overall Depth | 163 mm |
| Baffle Cutout Diameter | 355 mm |
| # Mounting Holes | 8 |
| Sealed Volume | 0.7 ft.³ |
| Sealed F3 | 101 Hz |
| Vented Volume | 1.55 ft.³ |
| Vented F3 | 65 Hz |
| Article number | PA380-8 |
| EAN | 0844632084249 |
Additional information
| Woofer Series | Dayton Audio PA series |
|---|---|
| Woofer Type | Midwoofer |
| Nominal Diameter | 15″ |
| Power Handling (RMS) | 500 Watts |
| Power Handling (max) | 1000 Watts |
| Impedance (Z) | 8 ohms |
| Sensitivity (SPL at 1m / 2.83V) | 96.1 dB |
| Frequency response | 28 – 3,500 Hz |
| Voice Coil Diameter | 76 mm |
| Magnet Weight | 80 oz. |
| DC Resistance (Re) | 6.3 ohms |
| Voice Coil Inductance (Le) | 4.12 mH @ 1 kHz |
| Resonant Frequency (Fs) | 31.6 Hz |
| Mechanical Q (Qms) | 12.20 |
| Electromagnetic Q (Qes) | 0.27 |
| Total Q (Qts) | 0.27 |
| Diaphragm Mass Inc. Airload (Mms) | 147g |
| Mechanical Compliance of Suspension (Cms) | 0.17 mm/N |
| Surface Area of Cone (Sd) | 845.0 cm² |
| Volume of Displacement (Vd) | 422.5 cm³ |
| BL Product (BL) | 25.8 Tm |
| Compliance Equivalent Volume (Vas) | 175 liters |
| Maximum Linear Excursion (Xmax) | 5 mm |
| Cone / Diaphragm Material | Paper / Carbon Fiber Cone |
| Surround Material | Cloth |
| Voice Coil Wire Material | Copper |
| Voice Coil Former | Kapton® / Polyimide |
| Basket / Frame Material | Steel |
| Magnet Material | Ferrite |
| Overall Outside Diameter | 380 mm |
| Overall Depth | 163 mm |
| Baffle Cutout Diameter | 355 mm |
| # Mounting Holes | 8 |
| Sealed Volume | 0.7 ft.³ |
| Sealed F3 | 101 Hz |
| Vented Volume | 1.55 ft.³ |
| Vented F3 | 65 Hz |
