Monacor SAM-200D Subwoofer Plate Amplifier
€184.95
Monacor SAM-200D Class D 200W Active Subwoofer Module
18 in stock
Description
Highlights
- High-performance active module in class D technology
- Variable low-pass filter: 40-200 Hz (18 dB)
- Continuously adjustable phase control 0-180° for perfectly matching it to the main speakers
- Line input, par. line output
- Integrated bass boost of approx. 3 dB at 40 Hz
- High power reserves
- Connections: 1 x RCA (line in), 1 x RCA (line out)
Product details
Due to state-of-the-art technology in the digital D class, the digital active subwoofer modules from IMG STAGELINE provide a powerful bass reproduction in self-built subwoofer systems. The components feature a high-power efficiency and provide an energy-saving operation. The lightweight design of these models which are available at an attractive price ensures a low total weight of the speaker system.
Specifications
| Article number | SAM-200D |
| EAN | 4007754228212 |
| Rated power output | <p>1 x 200 watts at 4 ohms</br>1 x 100 watts at 8 ohms</p> |
| Rated power output bridged | – |
| Minimum load | 4 ohms |
| Signal-to-noise ratio (SNR) | >70 dB |
| Distortion | <0.1% |
| Distortion bridged | – |
| Amplifier classification | Class D |
| Circuit topology | – |
| Efficiency | – |
| Frequency response | 20 – 200 Hz |
| Input impedance | <p>22k ohms (line level input) <br/> 270 ohms (high level input) </p> |
| Input sensitivity | </p>170 mV (line level input) </br> 1 V (high level input) </p> |
| Auto turn-on sensitivity | – |
| DSP | – |
| DAC | – |
| Maximum sampling rate | – |
| Speaker output channels | 1 |
| Analog in/out | 1/1 |
| S/PDIF in/out | -/- |
| AES/EBU in/out | -/- |
| Coaxial in/out | -/- |
| RCA in/out | 1/1 |
| XLR in/out | -/- |
| Jack in/out | -/- |
| USB connection | – |
| Network connection | – |
| Bluetooth | – |
| Subwoofer pre-out | – |
| Auto on/off | – |
| Remote control | – |
| App control | – |
| Equalizer (EQ) adjustment | – |
| Equalizer (EQ) profiles | – |
| Phase control | check |
| Crossover frequency adjustment | check |
| Presets | – |
| Control software | – |
| Windows/Mac compatible | -/- |
| Power requirements | 230 VAC |
| Power inlet connector | IEC C18 |
| Standby power consumption | <0.5 watts |
| Current limit | – |
| Under/over voltage protection | – |
| Dimensions (H x W x D) | 178 x 204 x 80 mm |
| Cutout dimensions | 158 x 184 mm |
| Article number | SAM-200D |
| EAN | 4007754228212 |
Additional information
| Rated power output | 1 x 200 watts at 4 ohms1 x 100 watts at 8 ohms |
|---|---|
| Minimum load | 4 Ohms |
| Signal-to-noise ratio (SNR) | >70 dB |
| Distortion | <0.1% |
| Amplifier classification | Class-D |
| Frequency response | 20 – 200 Hz |
| Input impedance | 22k ohms (line level input) 270 ohms (high level input) |
| Input sensitivity | 170 mV (line level input) 1 V (high level input) |
| Speaker output channels | 1 |
| Analog in/out | 1/1 |
| S/PDIF in/out | -/- |
| AES/EBU in/out | -/- |
| Coaxial in/out | -/- |
| RCA in/out | 1/1 |
| XLR in/out | -/- |
| Jack in/out | -/- |
| Phase control | check |
| Crossover frequency adjustment | check |
| Windows/Mac compatible | -/- |
| Power Requirements | 230 VAC |
| Power inlet connector | IEC C18 |
| Standby power consumption | <0.5 watts |
| Dimensions (H x W x D) | 178 x 204 x 80 mm |
| Cutout dimensions | 158 x 184 mm |
