Arylic Up2Stream amp 2.0 V4 WiFi and Bluetooth 5.0 Stereo Amplifier Board
€99.95
Does your next project require a high-end amplifier, Bluetooth 5.0 connection, Wi-Fi streaming, multi-room use or maybe even all of them? Then boy, do I have news for you! The brand new Up2Stream Amp V4 is here to satisfy all your needs!
2 in stock
Highlights
- Wireless streamer and amplifier in one
- Bluetooth 5.0 and Wi-Fi streaming using the free app
- Supports multi-room use.
Product details
Arylic Up2Stream amp 2.0 V4 WiFi and Bluetooth 5.0 Stereo Amplifier Board
Does your next project require a high-end amplifier, Bluetooth 5.0 connection, Wi-Fi streaming, multi-room use, or maybe even all of them? Boy, do I have good news for you! The brand new Up2Stream Amp is here to satisfy all your needs!
This amplifier can stream music off of any reputable streaming service using its free Android and iOS app; Wi-Fi, Bluetooth 5.0, DLNA, AirPlay, Spotify, Deezer, Tidal, Qobuz, iheartRadio, Napster, internet radio you name it. Not only is the app very useful for uncompressed music streaming, but it also allows you to change the name of every Arylic product on your network and to set up a multi-room sound system.
The amplifier uses a powerful low distortion class D amplifier chip outputting up to 50 Watts per channel into 4 Ohms. It features every connection one may need and even has a USB port that can either be used as a USB DAC or for USB storage of your favorite tracks.
To control the amplifier, the free app, a PC or the optional remote control can be used.
Specifications
| Article number | Up2Stream Amp 2.0 |
| EAN | 0691046949417 |
| Rated power output (RMS) | 2 x 50 watts at 4 ohms (21 V) |
| Bridged power output (RMS) | – |
| Minimum load | 4 Ohms |
| Signal-to-noise ratio (SNR) | 91 dB |
| Distortion | 0.03 % THD at 1 kHz, 50 Watts |
| Distortion bridged | – |
| Efficiency | – |
| Frequency response | 20 – 20,000 Hz |
| Input impedance | – |
| Input sensitivity | – |
| Auto turn-on sensitivity | – |
| DSP | – |
| DAC | micro-USB DAC |
| Maximum sampling rate | up to 24bit, 192kHZ |
| Circuit Topology | – |
| Amplifier classification | Class D |
| Speaker output channels | Left and Right |
| Subwoofer output channel | – |
| Analog in/out | 2/1 |
| Optical S/PDIF in/out | – |
| Coaxial in/out | – |
| RCA in/out | – |
| AUX in/out | – |
| Bus in/out | – |
| XLR in/out | – |
| USB | USB power, USB DAC, USB storage |
| Memory card slot | – |
| Network connection | check Single 10/100M RJ45 |
| Headphone jack | – |
| Subwoofer pre-out | – |
| Bluetooth | check Bluetooth 5.0 |
| NFC | – |
| Wi-Fi | check IEEE802.11 b/g/n 2.4G |
| Banana plug compatible | – |
| Remote control | check IR remote compatible |
| App control | check Free Android and iOS app |
| Auto turn-on | – |
| Accepted file formats | FLAC, MP3, AAC, AAC+, ALAC, APE, WAVE |
| Equalizer (EQ) adjustment | check in-app equalizer adjustment |
| Equalizer (EQ) profiles | – |
| Multi zone/room | check App supports Multi-Room playback |
| Crossover frequency adjustment | – |
| Bridge mode | – |
| Power requirements | DC 12V-26V 4A |
| Power inlet connector | 5.5 mm x 2.1 mm DC plug |
| Stand-by power consumption | – |
| Dimensions (D x W x H) | 80 x 100 x 20 mm |
| Article number | Up2Stream Amp 2.0 |
| EAN | 0691046949417 |
| Rated power output (RMS) | 2 x 50 watts at 4 ohms (21 V) |
|---|---|
| Minimum load | 4 Ohms |
| Signal-to-noise ratio (SNR) | 91 dB |
| Distortion | 0.03 % THD at 1 kHz, 50 Watts |
| Frequency response | 20 – 20,000 Hz |
| DAC | micro-USB DAC |
| Maximum sampling rate | up to 24bit, 192kHZ |
| Amplifier classification | Class-D |
| Speaker output channels | Left and Right |
| Analog in/out | 2/1 |
| USB | USB power, USB DAC, USB storage |
| Network connection | check Single 10/100M RJ45 |
| Bluetooth | check Bluetooth 5.0 |
| Wi-Fi | check IEEE802.11 b/g/n 2.4G |
| Remote control | check IR remote compatible |
| App control | check Free Android and iOS app |
| Accepted file formats | FLAC, MP3, AAC, AAC+, ALAC, APE, WAVE |
| Equalizer (EQ) adjustment | check in-app equalizer adjustment |
| Multi zone/room | check App supports Multi-Room playback |
| Power Requirements | DC 12V-26V 4A |
| Power inlet connector | 5.5 mm x 2.1 mm DC plug |
| Dimensions (D x W x H) | 80 x 100 x 20 mm |
